RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS

R01UH0575EJ0120 Rev. 1.20 Page 894 of 920

Dec 22, 2016

31.6 Analog Characteristics

31.6.1 A/D converter characteristics

Note 1. Excludes quantization error (±1/2 LSB).

Note 2. This value is indicated as a ratio (%FSR) to the full-scale value.

Note 3. When AVREFP < VDD, the MAX. values are as follows.

Overall error: Add ±1.0 LSB to the MAX. value when AV

REFP = VDD.

Zero-scale error/Full-scale error: Add ±0.05%FSR to the MAX. value when AV

REFP = VDD.

Integral linearity error/ Differential linearity error: Add ±0.5 LSB to the MAX. value when AV

REFP = VDD.

Note 4. When AVREFP < VDD, the MAX. values are as follows.

Overall error: Add ±4.0 LSB to the MAX. value when AV

REFP = VDD.

Zero-scale error/Full-scale error: Add ±0.20%FSR to the MAX. value when AV

REFP = VDD.

Integral linearity error/ Differential linearity error: Add ±2.0 LSB to the MAX. value when AV

REFP = VDD.

Classification of A/D converter characteristics

Reference Voltage

Input channel

Reference voltage (+) = AVREFP

Reference voltage (‒) = AVREFM

Reference voltage (+) = VDD

Reference voltage (‒) = VSS

ANI0 to ANI2, ANI13, ANI14, ANI19 Refer to 31.6.1 (1). Refer to 31.6.1 (2).

(1) When reference voltage (+) = AVREFP/ANI0 (ADREFP0 = 1),

reference voltage (‒) = AV

REFM/ANI1 (ADREFM = 1), target pin: ANI0 to ANI2, ANI13, ANI14, ANI19

A = ‒40 to +85 °C, 1.8 V ≤ VDD ≤ 3.6 V, 1.8 V ≤ AVREFP ≤ VDD ≤ 3.6 V, VSS = 0 V, Reference voltage (+) = AVREFP,

Reference voltage (‒) = AV

REFM = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Resolution RES 8 10 bit

Overall error

Note 1

AINL 10-bit resolution

REFP = VDD

Notes 3, 4

1.8 V ≤ AVREFP ≤ 3.6 V 1.2 ±5.0 LSB

Conversion time t

CONV 10-bit resolution

Target pin: ANI0 to ANI2, ANI13,

ANI14, ANI19

2.7 V

≤ VDD ≤ 3.6 V 3.1875 39 μs

1.8 V

≤ VDD ≤ 3.6 V 17 39 μs

Zero-scale error

Notes 1, 2

EZS 10-bit resolution

REFP = VDD

Notes 3, 4

1.8 V ≤ AVREFP ≤ 3.6 V ±0.35 %FSR

Full-scale error

Notes 1, 2

EFS 10-bit resolution

REFP = VDD

Notes 3, 4

1.8 V ≤ AVREFP ≤ 3.6 V ±0.35 %FSR

Integral linearity error

Note 1

ILE 10-bit resolution

REFP = VDD

Notes 3, 4

1.8 V ≤ AVREFP ≤ 3.6 V ±3.5 LSB

Differential linearity error

Note

DLE 10-bit resolution

REFP = VDD

Notes 3, 4

1.8 V ≤ AVREFP ≤ 3.6 V ±2.0 LSB

Analog input voltage V

AIN ANI0 to ANI2, ANI13, ANI14, ANI19 0 AVREFP V
