Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 6 CLOCK GENERATOR
R01UH0575EJ0120 Rev. 1.20 Page 138 of 920
Dec 22, 2016
6.6.7 Conditions before clock oscillation is stopped
The following lists the register flag settings for stopping the clock oscillation (disabling external clock input) and
conditions before the clock oscillation is stopped. Check the condition before stopping clock before stopping the
clock.
Table 6 - 13 Conditions Before the Clock Oscillation Is Stopped and Flag Settings
Clock
Conditions Before Clock Oscillation Is Stopped
(External Clock Input Disabled)
Flag Settings of SFR Register
High-speed on-chip oscillator
clock
MCS = 1 or CLS = 1
(The CPU is operating on a clock other than the high-
speed on-chip oscillator clock.)
HIOSTOP = 1
X1 clock MCS = 0 or CLS = 1
(The CPU is operating on a clock other than the
high-speed system clock.)
MSTOP = 1
External main system clock
XT1 clock CLS = 0
(The CPU is operating on a clock other than the
subsystem clock.)
XTSTOP = 1
External subsystem clock
