RL78/G1H CHAPTER 16 DATA TRANSFER CONTROLLER (DTC)
R01UH0575EJ0120 Rev. 1.20 Page 522 of 920
Dec 22, 2016
16.3.4 Peripheral enable register 1 (PER1)
The PER1 register is used to enable or disable supplying the clock to the peripheral hardware. Clock supply to
the hardware that is not used is also stopped so as to decrease the power consumption and noise.
When using the DTC, be sure to set bit 3 (DTCEN) to 1.
The PER1 register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 16 - 5 Format of Peripheral enable register 1 (PER1)
Address: F007AH After reset: 00H R/W
Symbol 7 6 5 4 <3> 2 1 <0>
PER1 0 0 0 0 DTCEN 0 0 TRJ0EN
DTCEN Control of DTC input clock supply
0 Stops input clock supply.
• DTC cannot run.
1 Enables input clock supply.
• DTC can run.
