19.3 Registers Controlling Interrupt Functions
The following 6 types of registers are used to control the interrupt functions.
• Interrupt request flag registers (IF0L, IF0H, IF1L, IF1H, IF2L, IF2H)
• IInterrupt mask flag registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H)
• Priority specification flag registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H, PR10L, PR10H, PR11L,
PR11H, PR12L, PR12H)
• External interrupt rising edge enable registers (EGP0, EGP1)
• External interrupt falling edge enable registers (EGN0, EGN1)
• Program status word (PSW)
Tables 19 - 3 to 19 - 5 show a list of interrupt request flags, interrupt mask flags, and priority specification flags
corresponding to interrupt request sources.
Table 19 - 3 Flags Corresponding to Interrupt Request Sources (1/3)
Interrupt Source Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag
Register Register Register
INTWDTI WDTIIF IF0L WDTIMK MK0L WDTIPR0, WDTIPR1 PR00L,
PR10L
INTLVI LVIIF LVIMK LVIPR0, LVIPR1
INTP0 PIF0 PMK0 PPR00, PPR10
INTP3 PIF3 PMK3 PPR03, PPR13
INTP4 PIF4 PMK4 PPR04, PPR14
INTCSI20 CSIIF20 IF0H CSIMK20 MK0H CSIPR020,
CSIPR120
PR00H,
PR10H
INTCSI21 CSIIF21 CSIMK21 CSIPR021,
CSIPR121
INTTM11H TMIF11H TMMK11H TMPR011H,
TMPR111H
INTTM01H TMIF01H TMMK01H TMPR001H,
TMPR101H
