RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS

R01UH0575EJ0120 Rev. 1.20 Page 710 of 920

Dec 22, 2016

Table 19 - 4 Flags Corresponding to Interrupt Request Sources (2/3)

Note 1. If one of the interrupt sources INTST1 and INTCSI10 is generated, bit 0 of the IF1L register is set to 1. Bit 0 of the MK1L,

PR01L, and PR11L registers supports these two interrupt sources.

Note 2. If one of the interrupt sources INTSR1 and INTCSI11 is generated, bit 1 of the IF1L register is set to 1. Bit 1 of the MK1L,

PR01L, and PR11L registers supports these two interrupt sources.

Note 3. Do not use a UART1 reception error interrupt and an interrupt of channel 3 of TAU0 (at higher 8-bit timer operation) at the

same time because they share flags for the interrupt request sources. When the UART1 reception error interrupt is not

used (EOC03 = 0), UART1 and channel 3 of TAU0 (at higher 8-bit timer operation) can be used at the same time. If either

of the interrupt sources INTSRE1 or INTTM03H is generated, bit 2 of the IF1H register is set to 1. Bit 2 of the MK1L,

PR01L, and PR11L registers support these two interrupt sources.

Note 4. If one of the interrupt sources INTST3, and INTCSI30 is generated, bit 4 of the IF1H register is set to 1. Bit 4 of the

MK1H, PR01H, and PR11H registers supports these two interrupt sources.

Interrupt Source

Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag

INTST1

Note 1

STIF1

Note 1

IF1L

STMK1

Note 1

MK1L

STPR01, STPR11

Note 1

PR01L,

PR11L

INTCSI10

Note 1

CSIIF10

Note 1

CSIMK10

Note 1

CSIPR010, CSIPR110

Note 1

INTSR1

Note 2

SRIF1

Note 2

SRMK1

Note 2

SRPR01, SRPR11

Note 2

INTSRE1

Note 3

SREIF1

Note 3

SREMK1

Note 3

SREPR01, SREPR11

Note 3

INTTM03H

Note 3

TMIF03H

Note 3

TMMK03H

Note 3

TMPR003H, TMPR103H

Note 3

INTIICA0 IICAIF0 IICAMK0 IICAPR00, IICAPR10

INTTM00 TMIF00 TMMK00 TMPR000, TMPR100

INTTM01 TMIF01 TMMK01 TMPR001, TMPR101

INTTM02 TMIF02 TMMK02 TMPR002, TMPR102

INTTM03 TMIF03 TMMK03 TMPR003, TMPR103

INTAD ADIF IF1H ADMK MK1H ADPR0, ADPR1 PR01H,

PR11H

INTRTC RTCIF RTCMK RTCPR0, RTCPR1

INTIT ITIF ITMK ITPR0, ITPR1

INTST3

Note 4

STIF3

Note 4

STMK3

Note 4

STPR03, STPR13

Note 4

INTCSI30

Note 4

CSIIF30

Note 4

CSIMK30

Note 4

CSIPR030, CSIPR130

Note 4

INTSR3 SRIF3 SRMK3 SRPR03, SRPR13

INTTRJ0 TRJIF0 TRJMK0 TRJPR00, TRJPR10

INTTM10 TMIF10 TMMK10 TMPR010, TMPR110
