RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS

R01UH0575EJ0120 Rev. 1.20 Page 711 of 920

Dec 22, 2016

Table 19 - 5 Flags Corresponding to Interrupt Request Sources (3/3)

Note Do not use a UART3 reception error interrupt and an interrupt of channel 3 of TAU1 (at higher 8-bit timer operation) at the

same time because they share flags for the interrupt request sources. When the UART3 reception error interrupt is not

used (EOC03 = 0), UART3 and channel 3 of TAU1 (at higher 8-bit timer operation) can be used at the same time. If either

of the interrupt sources INTSRE3 or INTTM13H is generated, bit 4 of the IF2H register is set to 1. Bit 4 of the MK2H,

PR02H, and PR12H registers support these two interrupt sources.

Interrupt Source

Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag

INTTM11 TMIF11 IF2L TMMK11 MK2L TMPR011, TMPR111 PR02L,

PR12L

INTTM12 TMIF12 TMMK12 TMPR012, TMPR112

INTTM13 TMIF13 TMMK13 TMPR013, TMPR113

INTP6 PIF6 PMK6 PPR06, PPR16

INTP7 PIF7 PMK7 PPR07, PPR17

INTP9 PIF9 PMK9 PPR09, PPR19

INTP10 PIF10 PMK10 PPR010, PPR110

INTP11 PIF11 IF2H PMK11 MK2H PPR011, PPR111 PR02H,

PR12H

INTSRE3

Note

SREIF3

Note

SREMK3

Note

SREPR03, SREPR13

Note

INTTM13H

Note

TMIF13H

Note

TMMK13H

Note

TMPR013H, TMPR113H

Note

INTIICA1 IICAIF1 IICAMK1 IICAPR01, IICAPR11

INTFL FLIF FLMK FLPR0, FLPR1
