RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 714 of 920
Dec 22, 2016
19.3.2 Interrupt mask flag registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H)
The interrupt mask flags are used to enable/disable the corresponding maskable interrupt.
The MK0L, MK0H, MK1L, MK1H, MK2L, and MK2H registers can be set by a 1-bit or 8-bit memory manipulation
instruction. When the MK0L and MK0H registers, the MK1L and MK1H registers, and the MK2L and MK2H
registers are combined to form 16-bit registers MK0, MK1, and MK2, they can be set by a 16-bit memory
manipulation instruction.
Reset signal generation sets these registers to FFH.
Remark If an instruction that writes data to this register is executed, the number of instruction execution clocks
increases by 2 clocks.
Figure 19 - 4 Format of Interrupt Mask Flag Registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H) (1/2)
Address: FFFE4H After reset: FFH R/W
Symbol 7 <6> <5> 4 3 <2> <1> <0>
MK0L 1 PMK4 PMK3 1 1 PMK0 LVIMK WDTIMK
Address: FFFE5H After reset: FFH R/W
Symbol <7> 6 5 4 3 <2> <1> <0>
MK0H TMMK01H 1 1 1 1 TMMK11H CSIMK21 CSIMK20
Address: FFFE6H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
MK1L TMMK03 TMMK02 TMMK01 TMMK00 IICAMK0
SREMK1
TMMK03H
SRMK1
STMK1
CSIMK10
Address: FFFE7H After reset: FFH R/W
Symbol <7> <6> <5> <4> 3 <2> <1> <0>
MK1H TMMK10 TRJMK0 SRMK3
STMK3
CSIMK30
1 ITMK RTCMK ADMK
Address: FFFD4H After reset: FFH R/W
Symbol <7> <6> 5 <4> <3> <2> <1> <0>
MK2L PMK10 PMK9 1 PMK7 PMK6 TMMK13 TMMK12 TMMK11
To Next Page
