Figure 19 - 5 Format of Interrupt Mask Flag Registers (MK0L, MK0H, MK1L, MK1H, MK2L, MK2H) (2/2)
Caution The available registers and bits differ depending on the product. For details about the registers and
bits available for each product, see Tables 19 - 3 to 19 - 5. Be sure to set bits that are not available to
the initial value.
Address: FFFD5H After reset: FFH R/W
Symbol <7> <6> 5 <4> 3 2 1 <0>
MK2H FLMK IICAMK1 1
SREMK3
TMMK13H
111PMK11
XXMKX Interrupt servicing control
0 Interrupt servicing enabled
1 Interrupt servicing disabled
