9.3.13 Alarm minute register (ALARMWM)
This register is used to set minutes of alarm.
The ALARMWM register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Caution Set a decimal value of 00 to 59 to this register in BCD code. If a value outside the range is set,
the alarm is not detected.
Figure 9 - 15 Format of Alarm minute register (ALARMWM)
9.3.14 Alarm hour register (ALARMWH)
This register is used to set hours of alarm.
The ALARMWH register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 12H.
However, the value of this register is 00H if the AMPM bit is set to 1 after reset.
Caution Set a decimal value of 00 to 23, 01 to 12, or 21 to 32 to this register in BCD code. If a value
outside the range is set, the alarm is not detected.
Figure 9 - 16 Format of Alarm hour register (ALARMWH)
Caution Bit 5 (WH20) of the ALARMWH register indicates AM(0)/PM(1) if AMPM = 0 (if the 12-hour system is
selected).
9.3.15 Alarm week register (ALARMWW)
This register is used to set date of alarm.
The ALARMWW register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 9 - 17 Format of Alarm week register (ALARMWW)
Address: FFF9AH After reset: 00H R/W
Symbol76543210
ALARMWM
0 WM40 WM20 WM10 WM8 WM4 WM2 WM1
Address: FFF9BH After reset: 12H R/W
Symbol76543210
ALARMWH
0 0 WH20 WH10 WH8 WH4 WH2 WH1
Address: FFF9CH After reset: 00H R/W
Symbol76543210
ALARMWW
0 WW6 WW5 WW4 WW3 WW2 WW1 WW0
