RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 582 of 920
Dec 22, 2016
Figure 18 - 21 Transmit/Receive Mode Register 4 (BBTXRXMODE4) Format
Caution Be sure to clear bit 1 to 3, 5 to “0”.
Address:
0011H
After reset: 01H R/W
Symbol76543210
BBTXRX
MODE4
TIMEOUTINT
SEL
TIMEOUTRCV
0 INTOUTSEL
0
0
0 CCAINTSEL
TIMEOUTIN
TSEL
Receive timeout interrupt switch bit
0 Byte receive interrupt
1 Receive timeout interrupt
TIMEOUTR
CV
Automatic receive with timeout after transmit enable bit
0 Automatic normal reception mode
1 Automatic reception with timeout mode
INTOUTSEL INTOUT output polarity switch bit
0 When with the interrupt request = INTOUT pin is at high level
1 When with the interrupt request = INTOUT pin is at low level
CCAINTSEL CCA interrupt select bit
0 Upon completion of the CCA sequence
1 Upon completion of the CSMA-CA sequence
To Next Page
