RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 616 of 920
Dec 22, 2016
(46) ACK receive wait time setting register (ACKRCVWIT)
This register is used to set the ACK receive wait time after the data transmission. Retransmits data when
there is no ACK reply even if it waits for the specified time. Initial value: 0300H = 768 symbols. (Set value:
1H = 1 symbol)
The ACKRCVWIT register consists of 16 bits and can be accessed (serial interface communication) in 8 bit
unit.
Reset signal generation sets this register to 0300H.
Figure 18 - 59 ACK Receive Wait Time Setting Register (ACKRCVWIT) Format
Address:
0071H, 0070H
After reset:
0300H
R/W
Symbol 15 14 13 12 11 10 9 8
ACKRCV
WIT
76543210
ACKRCVWIT ACK receive wait time
