(57) CCA time register (CCATIME)
This register is used to set the time taken for the CCA processing. Initial value: 000DH = 13 symbols (Set
value: 1H = 1 symbol).
Setting value is up to 2000 symbols.
CCATIME register is set via serial interface in 8-bit units.
Reset signal generation sets this register to 000DH.
Figure 18 - 70 CCA Time Register (CCATIME) Format
Caution The lower limit of setting value is in accordance with data rate. Refer to the latest application note for
setting values when to use the product.
Address:
00B3H, 00B2H
After reset: 000DH R/W
Symbol 15 14 13 12 11 10 9 8
CCATIME
76543210
CCATIME CCA time setting value
