SERVICE PROGRAM MODE 26 July 2002
5-42
5
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
11 Logout
Prevents initiators from logging on or makes initiators log
off.
[0 ∼ 1 / 0 / 1 /step]
• 0: Prevents the initiators (having already logged on) to
log on if they try to log on
• 1: Makes initiators (having already logged on) to log
off if they try to log on
12 Login Allows/disallows an initiator to exclusively log on.
[0 ∼ 1 / 0 / 1 /step]
• 0: Disallows
• 1: Allows
839
13 Login MAX Specifies the maximum initiators able to log on.
[0 ∼ 63 / 8 / 1 /step]
IEEE 802.11b
6 Channel MAX
Specifies the maximum number of IEEE 802.11b
channels.
North America: [1 ∼ 14 / 11 / 1 /step]
Europe: [1 ∼ 14 / 13 / 1 /step]
7 Channel MIN
Specifies the minimum number of IEEE 802.11b
channels.
[1 ∼ 14 / 1 / 1 /step]
840
11 WEP Key Select Selects the WEP key.
[00, 01, 10, 11 / 00 / – /step]
• 00: 1st key
• 01: 2nd key
• 10: 3rd key
• 11: 4th key
Toner Name Setting
1 Black
2 Cyan
3 Yellow
841
4 Magenta
Specifies supply names. These appear on the screen
when the user presses the Inquiry button in the user
tools screen.
Net File Analysis Mode Setting 842
1
Net File Analysis Mode
Setting
DFU
Default: 00111111 – do not change
Netfiles: Jobs to be printed from the document server
using a PC and the DeskTopBinder software
Input Check (Controller) 843
1
Input Check
(Controller)
[0x00 ∼ 0x07 / – / 1 /step] DFU
Default: 00000001 – do not change
Delivery Server
1 FTP Port No. Specifies the FTP port number.
[0 ∼ 65535 / 3670 / 1 /step]
2 IP address Specifies the distribution server IP address.
[0 ∼ 0xfffffff / 0x00 / – /step]
3 Retry Timer Specifies the distribution retry time.
[60 ∼ 900 / 300 / 1 /step]
4 Retry Times Specifies the distribution retry count.
[0 ∼ 99 / 3 / 1 /step]
845
5 IP (Capture Server) Specifies the distribution server address.
[0 ∼ 0xffffffff / 0x00 / 1 /step]
