SERVICE PROGRAM MODE 26 July 2002
5-48
6
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
ADF Free Run 009
1 ADF Free Run Executes an ADF free run.
[0 ∼ 1 / 0 / 1 /step]
• 0: End
• 1: Start
ADF Stamp Position 010
1 ADF Stamp Position Adjusts the stamp position of the optional ADF.
[–5.0 ∼ 5.0 / 0 / 0.1 mm/step]
ADF Size Change 016
1 ADF Size Change
Selects the paper size detected by the optional ADF
original sensors.
North America: [0 ∼ 1 / 0 / 1 /step]
Others: [0 ∼ 2 / 0 / 1 /step]
• 0: Regular
• 1: A4/LT
• 2: 8K/16K
Number 2, “8K/16K”, is valid for the models of the
following regions: Europe, Asia. When number 2 is
selected, the following paper sizes are not detected: A3,
B4, A4, B5.
Staple Position 050
1 Staple Position Adjusts the staple position of the optional finisher.
[–3.5 ∼ 3.5 / 0.0 / 0.5 mm/step]
Finisher Input Check
1 Entrance
2 Tray Exit
4 Staple Entrance
5 Stapler Home Position
6
Jogger Fence Home
Position
8
Feed-out Belt Home
Position
9 Stapler Tray Paper
10
Stapler Rotation Home
Position
11 Staple
14 Staple Sheet
17
Exit Plate Home
Position
18
Tray Shift Home
Position
21 Stack Height
23 Tray Lower Limit
35 Paper Limit
101 500 Fin Entrance
102 500 Fin Exit
103
500 Fin Jogger Home
Position
104 500 Fin Top Cover
105 500 Fin Height
117
106 500 Fin Lever
Displays the signals received from sensors and switches
in the finisher.
See section 5.1.4
