26 July 2002 SERVICE PROGRAM MODE
5-49
Service
Tables
6
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
107 500 Fin Upper Limit
108 500 Fin Near Limit
109 500 Fin Staple Cover
110
500 Fin Stapler Home
Position
111 500 Fin Staple End
112 500 Fin Staple
117
113 500 Fin Stapler Lock
Displays the signals received from sensors and switches
in the finisher.
See section 5.1.4
Output Check
1 Fin All Off
2 Upper Transfer Motor
3 Lower Transfer Motor
4 Exit Motor
5 Tray Gate Sol
6 Tray Lift Motor
7 Jogger Motor
12 Stapler Motor
13 Staple Hummer
15 Stapler Gate Sol
16 Pos. Roller Sol
18 Feed-out Motor
19 Shift Motor
22 Guide Plate Motor
23 Fin Free Run 1
24 Fin Free Run 2
101 500 Fin All Off
102 500 Fin Main Motor
103 500 Fin Jogger Motor
104 500 Fin Paddle Sol
105 500 Fin Gear Sol
106 500 Fin Lever Sol
107 500 Fin Tray Motor
108 500 Fin Stapler Motor
109 500 Fin Free Run 1
118
110 500 Fin Free Run 2
Switches on each electrical component of the finisher.
See section 5.1.5
ADF Read Position Adjustment 990
1
ADF Read Position
Adjustment
Adjusts the reading position of the ADF. Moves the
scanner under the glass to a different position. Use this
if there is a scratch on the glass.
[–10 ∼ 10 / 0 / 0.1 mm/step]
