26 July 2002 COPIER (B051/B052)
1-9
Installation
8. Keep the development unit level and shake the development unit about 10
times from side to side.
NOTE: 1) Do not touch the development roller or the development roller gear.
2) Use caution not to drop the cartridge or to damage it.
3) If the cartridge has not been shaken well, the machine takes a
longer time to initialize the development unit, or an error message or
SC350 is displayed. When either of them is displayed, turn the main
switch off and on.
9. Engage the special tool [A] (distributed with the machine) with the development
roller gear at the rear [B].
10. Turn the tool clockwise (approximately 5 times) until the toner covers the whole
area of the development roller [C].
NOTE: If the toner does not cover the whole area of the development roller,
redo step 8 to 10.
B051I315.WMF
B051I409.WMF
[A]
[C]
Rear view
[B]
