COPIER (B051/B052) 26 July 2002
1-10
11. Reinstall the development units, and close the left cover.
NOTE: A white line or band may appear on one end of the paper if a
development is incorrectly installed. To correct this, pull out the
development unit partially (about 30 mm) and slowly reinstall it.
12. Remove the oil tank cover [A] (1 clip), and fill the oil tank to the maximum line.
NOTE: Do not fill the oil tank past the arrow [B].
B051I135.WMF
[A]
[B]
