The State displays the current PTPslave state. The LED will change according to
the current state:
Green: Slave
Yellow: Listening, Uncalibrated
Red: Faulty
Grey:Disabled
The Domain displays based on the current configuration.
The Delay reflects the path delay between master and slave.
The Offset is the current offset to Master.
The Clock Accuracy displays as reported by the PTP data.
The Datasets button displays the Datasets popup window (see "The
PTPDatasets Panel " on page146).
The Statistics button displays the Statistics popup window (see "The PTP Stat-
istics Panel" on page147).
The Settings button brings up the popup window to edit settings (see "The
Edit PTP Settings Panel" below).
The Delete button removes the configuration on a given Ethernet port and
will return all settings to default.
The Plus symbol adds a new PTPSlave and brings up the Edit PTP Settings
popup window.
The Edit PTP Settings Panel
The Edit PTP Settings Panel displays when the plus symbol to add a new Master
or Slave is selected, or when the Settings button next to a configured PTP Eth-
ernet port is selected. The settings panel provides access to the configuration set-
tings, as described below. When you are finished with your configuration, select
Submit (you could also choose to Restore defaults).
Note: The PTP settings fields visible will change based on profile
selection and other choices made in the configuration process.
