SATO CL4NX Plus User Manual

[Advanced]
238
[Finisher Feed]
Set the media feed amount for Tear-off, cut and dispense stop. Set the media feed amount based on
the print head position of 0.
The actual media feed amount is the value of [Offset] + [Finisher Feed].
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution CL4NX Plus
203 dpi
(1 dot = 0.125 mm (0.0049"))
0 to 2040 dots
305 dpi
(1 dot = 0.083 mm (0.0033"))
0 to 3060 dots
609 dpi
(1 dot = 0.042 mm (0.0017"))
0 to 6120 dots
• When [Printing Mode] is set to [Use Ribbon], the length of label backfeed needs to be
under 30 mm (1.18"). If it is over 30 mm (1.18"), the end of the ribbon may be falsely
detected.
• A message prompting you to restart the product will appear on the Online/Offline
screen if you have made any changes. In such a case, reboot the product to apply the
settings.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
