[RS-232C]
358
Refer to the table below for the parameter configurations.
• [8-N-1]
• [8-O-1]
• [8-E-1]
• [8-N-2]
• [8-O-2]
• [8-E-2]
• [7-N-1]
• [7-O-1]
• [7-E-1]
• [7-N-2]
• [7-O-2]
• [7-E-2]
Parameter Configurations List
Parameters Data length
(bit)
Parity Stop bit
(bit)
8-N-1 8 NONE 1
8-O-1 8 ODD 1
8-E-1 8 EVEN 1
8-N-2 8 NONE 2
8-O-2 8 ODD 2
8-E-2 8 EVEN 2
7-N-1 7 NONE 1
7-O-1 7 ODD 1
7-E-1 7 EVEN 1
7-N-2 7 NONE 2
7-O-2 7 ODD 2
7-E-2 7 EVEN 2
