SATO CL4NX Plus User Manual

493
If reading is successful, the code type and read data are displayed. The data is displayed only up to 23
bytes from the beginning.
If the reading is unsuccessful, or if the displayed read result is not correct, adjust the position of the
barcode checker by operating the barcode checker stand. For details on how to use the barcode
checker stand, refer to the Barcode Checker Stand Kit Installation Manual that came with the barcode
checker stand kit.
[Interface]
Set the RS-232C interface usage.
The options are as follows:
RS-232C
Use the RS-232C interface for communicating with computers.
RS-232C Reader
Select this when you connect the KEYENCE barcode checkers for the barcode check function.
• A message prompting you to restart the product will appear on the Online/Offline
screen if you have made any changes. In such a case, reboot the product to apply the
settings.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
