4.124
SEL-751A Relay Instruction Manual Date Code 20100129
Protection and Logic Functions
DNP Map Settings (Set DNP n command, n = 1, 2, or 3)
Event Report Settings
Event reports can be either 15 cycles or 64 cycles in length as determined by
the LER setting. For LER of 15, the prefault length, PRE, must be in the range
1–10. The relay can hold as many as seventy-seven 15-cycle event reports or
nineteen 64-cycle event reports.
Load Profile Settings
Use the LDLIST setting to declare the analog quantities you want included in
the Load Profile Report. Enter up to 17 analog quantities, separated by spaces
or commas, into LDLIST setting. See Appendix K: Analog Quantities for a list
of the available Analog Quantities. Also set the LDAR to the desired
acquisition rate for the report.
IMPORTANT: All stored load data
are lost when changing the LDLIST.
DNP Map Settings (Set DNP n command, n = 1, 2, or 3)
Table 4.74 shows the available settings. See Appendix D: DNP3
Communications for additional details.
Table 4.72 Event Report Settings
Setting Prompt Setting Range Setting Name := Factory Default
EVENT TRIGGER SELOGIC ER := R_TRIG 51P1P OR R_TRIG 51G1P
OR R_TRIG 50P1P OR R_TRIG 50G1P
OR R_TRIG 51N1P OR R_TRIG CF
EVENT LENGTH 15, 64 cyc LER := 15
PREFAULT LENGTH 1–59 cyc PRE := 5
NOTE: Event report data stored in
the relay will be lost when you
change the LER setting, You must
save the data before changing the
setting.
Table 4.73 Load Profile Settings
Setting Prompt Setting Range
Setting Name :=
Factory Defau lt
LDP LIST 0, Up to 17 Analog Quantities LDLIST := 0
LDP ACQ RATE 5, 10, 15, 30, 60 min LDAR := 15
Table 4.74 DNP Map Settings
a
(Sheet 1 of 2)
Setting Prompt Setting Range
Setting Name := Factory
Default
DNP Binary Input Label Name
10 characters BI_00 := ENABLED
DNP Binary Input Label Name
10 characters BI_01 := TRIP_LED
DNP Binary Input Label Name
10 characters BI_02 := TLED_01
DNP Binary Input Label Name
10 characters BI_03 := TLED_02
·
·
·
DNP Binary Input Label Name
10 characters BI_99 := NA
