Sel 751A - Figure D.4 Port MAP Command

D.15
Date Code 20100129 Instruction Manual SEL-751A Relay
DNP3 Communications
DNP3 in the SEL-751A
=>MAP DNP 1 1 <Enter>
SEL-751A Date: 12/14/2008 Time: 09:33:39
FEEDER RELAY Time Source: Internal
Map 1
Transport TCP
Device IP Address 10.201.5.3
Master IP Address 10.200.0.139
Device DNP TCP and UDP Port 20000
Device DNP Address 15
Master DNP Address 0
Binary Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SER TIMESTAMP
0 ENABLED 1 No
1 TRIP_LED 1 No
2 TLED_011 No
3 TLED_021 No
…
97 IN1011 No
98 IN1021 No
99 5P1P1 No
Binary Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 RB01
1 RB02
2 RB03
…
29 RB30
30 RB31
31 RB32
Counters
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS DEADBAND
0 SC01 0 1
1 SC02 0 1
2 SC03 0 1
…
29 SC30 0 1
30 SC31 0 1
31 SC32 0 1
Analog Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SCALE FACTOR DEADBAND
0 IA_MAG 2 10.0000 1000
1 IB_MAG 2 10.0000 1000
2 IC_MAG 2 10.0000 1000
3 IG_MAG 2 10.0000 1000
4 IN_MAG2 10.0000 1000
5 IAV2 10.0000 1000
6 3I2 2 10.0000 1000
7FREQ 2 1.0000 100
8VAB_MAG 2 10.0000 2000
9VBC_MAG 2 10.0000 2000
10VCA_MAG 2 10.0000 2000
11VAVE2 10.0000 2000
123V22 10.0000 2000
…
…
96 P 2 10.0000 100
97 Q 2 10.0000 100
98 S 2 10.0000 100
99 PF 2 10.0000 100
Analog Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 GROUP
1 NOOP
Figure D.4 Port MAP Command
You can use the command SET DNP x, where x is the map number, to edit or
create custom DNP3 data maps. You can also use the
ACSELERATOR
QuickSet
®
SEL-5030 Software, which is recommended for this purpose.
