3.6
SEL-751A Relay Instruction Manual Date Code 20100129
PC Software
Settings
Create a New Database, Copy an Existing Database
To create and copy an existing database of devices to a new database:
Step 1. Click File > Database Manager, and select the Create New
Database button.
ACSELERATOR QuickSet prompts you for a
file name.
Step 2. Type the new database name (and location if the new location
differs from the existing one), and click Save.
ACSELERATOR
QuickSet displays the message
Settings [path and
filename] was successfully created
.
Step 3. Click OK.
To copy an exiting database of devices to a new database:
Step 1. Click File > Database Manager, and select the Copy/Move
Settings Between Databases tab in the Database Manager
dialog box.
ACSELERATOR QuickSet opens the last active database and
assigns it as Database A.
Step 2. Click the Open B button;
ACSELERATOR QuickSet prompts
you for a file location.
Step 3. Type a new database name, click the Open button, and click
Yes; the program creates a new empty database. Load devices
into the new database as in Copy/Move Settings Between
Databases on page 3.5.
Settings
ACSELERATOR QuickSet offers the capability of creating settings for one or
more SEL-751A
relays. Store existing relay settings downloaded from
SEL-751A
relays with ACSELERATOR QuickSet, creating a library of relay
settings, then modify and upload these settings from the settings library to an
SEL-751A.
ACSELERATOR QuickSet makes setting the relay easy and
efficient. However, you do not have to use
ACSELERATOR QuickSet to
configure the SEL-751A; you can use an ASCII terminal or a computer
running terminal emulation software.
ACSELERATOR QuickSet provides the
advantages of rules-based settings checks, SEL
OGIC
®
control equation
Expression Builder, operator control and metering HMI, event analysis, and
help.
Settings Editor
The Settings Editor shows the relay settings in easy-to-understand categories.
The SEL-751A settings structure makes setting the
relay easy and efficient.
Settings are grouped logically, and
relay elements that are not used in the
selected protection scheme are not accessible. For example, if there is only
one analog card installed in the
relay, you can access settings for this one card
only. Settings for the other slots are dimmed (grayed) in the
ACSELERATOR
QuickSet menus.
ACSELERATOR QuickSet shows all of the settings categories
in the settings tree view. The settings tree view remains constant whether
settings categories are enabled or disabled. However, any disabled settings are
dimmed when accessed by clicking an item in the tree view.
