8.13
Date Code 20100129 Instruction Manual SEL-751A Relay
Front-Panel Operations
Operation and Target LEDs
The SEL-751A can be ordered with optional slide-in labels for custom LED
designations that match custom LED logic. The Configurable Label kit
(includes blank labels, word processor templates, and instructions) is provided
when the SEL-751A is ordered with the Configurable Labels option.
The ENABLED LED indicates that the relay is powered correctly, is functional,
and has no self-test failures. Trip events illuminate the TRIP LED. The
prominent location of the TRIP LED in the top target area aids in recognizing
trip events quickly.
The TRIP LED has an additional function that notifies you of warning
conditions. When the TRIP LED is flashing, the warning conditions in
Table 8.3 are active when you set the corresponding relay element. For Relay
Word bit definitions see Appendix J: Relay Word Bits.
{TARGET RESET}
Pushbutton
Target Reset
For a trip event, the SEL-751A latches the trip-involved target LEDs except
for the ENABLED LED. Press the {TARGET RESET} pushbutton to reset the latched
target LEDs. When a new trip event occurs and the previously latched trip
targets have not been reset, the relay clears the latched targets and displays the
new trip targets. Pressing and holding the {TARGET RESET} pushbutton
illuminates all the LEDs. Upon release of the {TARGET RESET} pushbutton, two
possible trip situations can exist: the conditions that caused the relay to trip
have cleared, or the trip conditions remain present at the relay inputs. If the
trip conditions have cleared, the latched target LEDs turn off. If the trip event
conditions remain, the relay re-illuminates the corresponding target LEDs.
The {TARGET RESET} pushbutton also removes the trip automatic message
displayed on the LCD menu screens if the trip conditions have cleared.
Figure 8.25 Target Reset Pushbutton
Lamp Test
The {TARGET RESET} pushbutton also provides a front-panel lamp test. Pressing
and holding {TARGET RESET} illuminates all the front-panel LEDs, and these
LEDs remain illuminated for as long as {TARGET RESET} is pressed. The target
LEDs return to a normal operational state after release of the {TARGET RESET}
pushbutton.
Table 8.3 Possible Warning Conditions (Flashing TRIP LED)
Relay Word Bits
55A BRGALRM OTHALRM
AFTALARM COMMIDLE RTDFLT
AMBALRM COMMLOSS WDGALRM
