Sel 751A - Modbus Map Settings (SET M Command); Table 4.75 User Map Register Settings

4.125
Date Code 20100129 Instruction Manual SEL-751A Relay
Protection and Logic Functions
Modbus Map Settings (SET M Command)
Modbus Map Settings (SET M Command)
Modbus User Map
Table 4.75 shows the available settings. See Appendix E: Modbus RTU
Communications for additional details.
DNP Binary Output Label Name
10 characters BO_00 := RB01
·
·
·
DNP Binary Output Label Name
10 characters BO_31 := RB32
DNP Analog Input Label Name
24 characters AI_00 := IA_MAG
DNP Analog Input Label Name
24 characters AI_01 := IB_MAG
·
·
·
DNP Analog Input Label Name
24 characters AI_99 := NA
DNP Analog Output Label Name
6 characters AO_00 := NA
·
·
·
DNP Analog Output Label Name
6 characters AO_31 := NA
DNP Counter Label Name
11 characters CO_00 := NA
·
·
·
DNP Counter Label Name
11 characters CO_31 := NA
a
See Appendix D: DNP3 Communications for complete list of the DNP Map Labels and factory
default settings.
Table 4.74 DNP Map Settings
a
(Sheet 2 of 2)
Setting Prompt Setting Range
Setting Name := Factory
Default
Table 4.75 User Map Register Settings
a
a
See Appendix E: Modbus RTU Communications for Modbus Register Labels and factory
default settings.
Setting Prompt Setting Range
Setting Name :=
Factory Defau lt
USER REG#1 NA, 1 Modbus Register Label MOD_001 :=
•••
•••
•••
USER REG#125 NA, 1 Modbus Register Label MOD_125 :=
