D.25
Date Code 20100129 Instruction Manual SEL-751A Relay
DNP3 Communications
DNP3 Documentation
Reference Data Map
Table D.12 shows the SEL-751A reference data map. The reference map
shows the data available to a DNP3 master. You can use the default map or the
custom DNP3 mapping functions of the SEL-751A to retrieve only the points
required by your application.
NOTE: Dead-band changes via
Object 34 are not stored in nonvolatile
memory. Make sure to reissue the
Object 34 dead bands after a warm
(STA C) or cold start (power cycle).
The SEL-751A scales analog values by the indicated settings or fixed scaling
indicated in the description. Analog dead bands for event reporting use the
indicated settings, or ANADBM if you have not specified a setting.
113 All Virtual Terminal Event Data
N/A No object required for the following
function codes:
13 cold start
14 warm start
23 delay measurement
13, 14, 23
a
Supported in requests from master.
b
May generate in response to master.
c
Decimal.
d
Hexadecimal.
e
Default variation.
Table D.11 SEL-751A DNP Object List (Sheet 5 of 5)
Obj. Var. Description
Request
a
Response
b
Funct. Codes
c
Qual. Codes
d
Funct. Codes
c
Qual. Codes
d
Table D.12 DNP3 Reference Data Map (Sheet 1 of 2)
Object. Labels Description
Binary Inputs
01, 02 STFAIL
STWARN
STSET
Enabled–TLED_06 Relay Word Elements Target Row 0 (see Ta ble J.1)
50A1P-AFS4EL Relay Word Elements (see Tab le J. 1)
PFL Power Factor Leading for Three-Phase Currents
0 Logical 0
1 Logical 1
Binary Outputs
10, 12 RBxx Remote Bits (xx = 01–32)
CC Breaker Close Bit
OC Breaker Open Bit
Counters
20, 22 SCxx SELOGIC Counter Values (xx = 01–32)
GROUP Active Settings Group
Analog Inputs
30, 32, 34 IA_MAG–SC32 Analog Quantities from Table K . 1 with an “x” in the
DNP column
SER_NUM Serial Number
0 Numeric 0
1 Numeric 1
NOTE: Although not shown as part
of the reference maps you may use
any Relay Word bit label when
creating custom maps.
