SEL-751A Settings Sheets
Group Settings (SET Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
Residual Time Overcurrent
TOC TRIP LVL (OFF, 0.50–16.00 A {5 A nom.}, 0.10–3.20 A
{1 A nom.})
51G1P :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51G1P := OFF)
51G1C :=
TOC TIME DIAL (0.50–15.00 {if 51_C := U_}, 0.05–1.00 {if
51_C := C_})
(Hidden if 51G1P := OFF)
51G1TD :=
EM RESET DELAY (Y, N)
(Hidden if 51G1P := OFF) 51G1RS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51G1P := OFF)
51G1CT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51G1P := OFF)
51G1MR :=
TOC TRQ CONTROL (SEL
OGIC) (Hidden if 51G1P := OFF) 51G1TC :=
TOC TRIP LVL (OFF, 0.50–16.00 A {5 A nom.}, 0.10–3.20 A
{1 A nom.})
51G2P :=
TOC CURVE SEL (U1, U2, U3, U4, U5, C1, C2, C3, C4, C5)
(Hidden if 51G2P := OFF)
51G2C :=
TOC TIME DIAL (0.50–15.00 {if 51_C := U_}, 0.05–1.00 {if
51_C := C_})
(Hidden if 51G2P := OFF)
51G2TD :=
EM RESET DELAY (Y, N)
(Hidden if 51G2P := OFF) 51G2RS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51G2P := OFF)
51G2CT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51G2P := OFF)
51G2MR :=
TOC TRQ CONTROL (SEL
OGIC) (Hidden if 51G2P := OFF) 51G2TC :=
RTD (Hidden if RTD card and Port 2 not included)
RTD ENABLE (INT, EXT, NONE)
(All RTD settings below Hidden if E49RTD := NONE)
E49RTD :=
RTD1 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD1LOC :=
RTD1 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD1LOC := OFF)
RTD1TY :=
RTD1 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD1LOC := OFF)
TRTMP1 :=
RTD1 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD1LOC := OFF)
ALTMP1 :=
RTD2 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD2LOC :=
RTD2 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD2LOC := OFF)
RTD2TY :=
RTD2 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD2LOC := OFF)
TRTMP2 :=
RTD2 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD2LOC := OFF)
ALTMP2 :=
