SEL-751A Settings Sheets
Group Settings (SET Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
RTD9 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD9LOC := OFF)
RTD9TY :=
RTD9 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD9LOC := OFF)
TRTMP9 :=
RTD9 WARN LEVEL (OFF, 1–250 degC)
(
Hidden if RTD9LOC := OFF)
ALTMP9 :=
RTD10 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD10LOC:=
RTD10 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD10LOC := OFF)
RTD10TY :=
RTD10 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD10LOC := OFF)
TRTMP10 :=
RTD10 WARN LEVEL (OFF, 1–250 degC)
(
Hidden if RTD10LOC := OFF)
ALTMP10 :=
RTD11 LOCATION (OFF, WDG, BRG, AMB, OTH)
(Hidden if E49RTD := INT)
RTD11LOC:=
RTD11 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD11LOC := OFF or E49RTD := INT)
RTD11TY :=
RTD11 TRIP LEVE (OFF, 1–250 degC)
(Hidden if RTD11LOC := OFF or E49RTD := INT)
TRTMP11 :=
RTD11 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD11LOC := OFF or E49RTD := INT)
ALTMP11 :=
RTD12 LOCATION (OFF, WDG, BRG, AMB, OTH)
(Hidden if E49RTD := INT)
RTD12LOC:=
RTD12 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD12LOC := OFF or E49RTD := INT)
RTD12TY :=
RTD12 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD12LOC := OFF or E49RTD := INT)
TRTMP12 :=
RTD12 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD12LOC := OFF or E49RTD := INT)
ALTMP12 :=
WIND TRIP VOTING (Y, N)
(Hidden if less than 2 locations are
WDG)
EWDGV :=
BEAR TRIP VOTING (Y, N)
(Hidden if less than 2 locations are
BRG)
EBRGV :=
Undervoltage
(All or some of the settings below are hidden if appropriate Voltage Card Option not
included, see Table 1.1)
UV TRIP1 LEVEL (OFF, 0.02–1.00 xVnm) 27P1P :=
UV TRIP1 DELAY (0.0–120.0 sec)
(Hidden if 27P1P := OFF) 27P1D :=
UV TRIP2 LEVEL (OFF, 0.02–1.00 xVnm)
27P2P :=
UV TRIP2 DELAY (0.0–120.0 sec)
(Hidden if 27P2P := OFF) 27P2D :=
UVS LEVEL 1 (OFF, 2.00–300.00 V)
27S1P :=
UVS DELAY 1 (0.0–120.0 sec)
(Hidden if 27S1P := OFF) 27S1D :=
