Sel 751A - Page 257

Date _______________
Date Code 20100129 Instruction Manual SEL-751A Relay
SET.7
of 68
SEL-751A Settings Sheets
Group Settings (SET Command)
RTD3 LOCATION (OFF, WDG, BRG, AMB, OTH) RTD3LOC :=
RTD3 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD3LOC := OFF)
RTD3TY :=
RTD3 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD3LOC := OFF)
TRTMP3 :=
RTD3 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD3LOC := OFF)
ALTMP3 :=
RTD4 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD4LOC :=
RTD4 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD4LOC := OFF)
RTD4TY :=
RTD4 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD4LOC := OFF)
TRTMP4 :=
RTD4 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD4LOC := OFF)
ALTMP4 :=
RTD5 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD5LOC :=
RTD5 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD5LOC := OFF)
RTD5TY :=
RTD5 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
TRTMP5 :=
RTD5 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
ALTMP5 :=
RTD6 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD6LOC :=
RTD6 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD6LOC := OFF)
RTD6TY :=
RTD6 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
TRTMP6 :=
RTD6 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
ALTMP6 :=
RTD7 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD7LOC :=
RTD7 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD7LOC := OFF)
RTD7TY :=
RTD7 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
TRTMP7 :=
RTD7 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
ALTMP7 :=
RTD8 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD8LOC :=
RTD8 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD8LOC := OFF)
RTD8TY :=
RTD8 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
TRTMP8 :=
RTD8 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
ALTMP8 :=
RTD9 LOCATION (OFF, WDG, BRG, AMB, OTH)
RTD9LOC :=
