Sel 751A - Table E.31 Modbus Register Labels for Use with SET M Command

E.21
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Communications Protocol
Inst ruction Manual
Table E.31 Modbus Register Labels for Use With SET M Command (Sheet 1 of 5)
Register
Address
Label
610 FPGA
611 GPSB
612 HMI
613 RAM
614 ROM
615 CR_RAM
616 NON_VOL
617 CLKSTS
618 CID_FILE
619 RTD
620 P3P3PS
621 P5PS
622 P2P5PS
623 P3P75PS
624 N1P25PS
625 N5PS
626 CLKBAT
627 CTBRD
628 CARDC
629 CARDD
630 CARDE
631 IASTS
632 IBSTS
633 ICSTS
634 INSTS
635 VASTS
636 VBSTS
637 VCSTS
638 RLYSTS
639 VSSTS
640 SER_NUMH
641 SER_NUML
642 RES_642
643 RES_643
644 RES_644
645 RES_645
646 RES_646
647 RES_647
648 RES_648
649 RES_649
650 IA_MAG
651 IA_ANG
652 IB_MAG
653 IB_ANG
654 IC_MAG
655 IC_ANG
656 IN_MAG
657 IN_ANG
658 IG_MAG
659 IG_ANG
660 IAV
661 RES_661
662 3I2
663 UBI
664 VS_MAG
665 VS_ANG
666 VDC
667 VAB_MAG
668 VAB_ANG
669 VBC_MAG
670 VBC_ANG
671 VCA_MAG
672 VCA_ANG
673 VAVE
674 VA_MAG
675 VA_ANG
676 VB_MAG
677 VB_ANG
678 VC_MAG
679 VC_ANG
680 VG_MAG
681 VG_ANG
682 VAVE
683 3V2
684 UBV
685 P
686 Q
687 S
688 PF
689 FREQ
690 MWH3PH
691 MWH3PL
692 MVRH3PIH
693 MVRH3PIL
694 MVRH3POH
695 MVRH3POL
696 MVAH3PH
697 MVAH3PL
698 ENRGY_S
699 ENRGYMN
700 ENRGY_H
701 ENRGY_D
702 ENRGYMO
703 ENRGY_Y
704 MWH3PIH
705 MWH3PIL
706 RES_706
707 RES_707
708 RES_708
709 RES_709
710 RES_710
711 RES_711
712 RTDWDGMX
713 RTDBRGMX
714 RTDAMB
715 RTDOTHMX
716 RTD1
717 RTD2
Register
Address
Label
718 RTD3
719 RTD4
720 RTD5
721 RTD6
722 RTD7
723 RTD8
724 RTD9
725 RTD10
726 RTD11
727 RTD12
728 RES_728
729 LSENS1
730 LSENS2
731 LSENS3
732 LSENS4
733 RES_733
734 RES_734
735 RES_735
736 RES_736
737 RES_737
738 RES_738
739 VSRMS
740 IARMS
741 IBRMS
742 ICRMS
743 INRMS
744 VARMS
745 VBRMS
746 VCRMS
747 VABRMS
748 VBCRMS
749 VCARMS
750 IAMX
751 IAX_S
752 IAXMN
753 IAX_H
754 IAX_D
755 IAXMO
756 IAX_Y
757 IAMN
758 IAN_S
759 IANMN
760 IAN_H
761 IAN_D
762 IANMO
763 IAN_Y
764 IBMX
765 IBX_S
766 IBXMN
767 IBX_H
768 IBX_D
769 IBXMO
770 IBX_Y
771 IBMN
Register
Address
Label
772 IBN_S
773 IBNMN
774 IBN_H
775 IBN_D
776 IBNMO
777 IBN_Y
778 ICMX
779 ICX_S
780 ICXMN
781 ICX_H
782 ICX_D
783 ICXMO
784 ICX_Y
785 ICMN
786 ICN_S
787 ICNMN
788 ICN_H
789 ICN_D
790 ICNMO
791 ICN_Y
792 INMX
793 INX_S
794 INXMN
795 INX_H
796 INX_D
797 INXMO
798 INX_Y
799 INMN
800 INN_S
801 INNMN
802 INN_H
803 INN_D
804 INNMO
805 INN_Y
806 IGMX
807 IGX_S
808 IGXMN
809 IGX_H
810 IGX_D
811 IGXMO
812 IGX_Y
813 IGMN
814 IGN_S
815 IGNMN
816 IGN_H
817 IGN_D
818 IGNMO
819 IGN_Y
820 VABMX
821 VABX_S
822 VABXMN
823 VABX_H
824 VABX_D
825 VABXMO
Register
Address
Label
826 VABX_Y
827 VABMN
828 VABN_S
829 VABNMN
830 VABN_H
831 VABN_D
832 VABNMO
833 VABN_Y
834 VBCMX
835 VBCX_S
836 VBCXMN
837 VBCX_H
838 VBCX_D
839 VBCXMO
840 VBCX_Y
841 VBCMN
842 VBCN_S
843 VBCNMN
844 VBCN_H
845 VBCN_D
846 VBCNMO
847 VBCN_Y
848 VCAMX
849 VCAX_S
850 VCAXMN
851 VCAX_H
852 VCAX_D
853 VCAXMO
854 VCAX_Y
855 VCAMN
856 VCAN_S
857 VCANMN
858 VCAN_H
859 VCAN_D
860 VCANMO
861 VCAN_Y
862 KW3PMX
863 KW3X_S
864 KW3XMN
865 KW3X_H
866 KW3X_D
867 KW3XMO
868 KW3X_Y
869 KW3PMN
870 KW3N_S
871 KW3NMN
872 KW3N_H
873 KW3N_D
874 KW3NMO
875 KW3N_Y
876 KVAR3PMX
877 KVR3X_S
878 KVR3XMN
879 KVR3X_H
Register
Address
Label
