IEC 61850 Communications
Logical Nodes
Table F.14 shows the LN associated with control elements defined as Logical
Device CON.
Table F.15 shows the LN associated with annunciation elements defined as
Logical Device ANN.
Table F.14 Logical Device: CON (Control)
Logical Node Status Control Relay Word Bit
RBGGIO1 SPCSO01.stVal to SPCSO32.stVal SPCSO01.ctlVal to SPCSO32.ctlVal Remote Bits (RB01 to RB32)
Table F.15 Logical Device: ANN (Annunciation)
Logical Node Status Relay Word Bit
Analog Quantities
MVGGIO12 AnIn01.mag to AnIn32.mag Math Variables (MV01 to MV32)
a
SCGGIO20 AnIn01.mag to AnIn32.mag SELOGIC Counters (SC01 to SC32)
b
AINCGGIO21 AnIn01.mag to AnIn08.mag Analog Inputs (AI301 to AI308)—Slot C
c
AINDGGIO22 AnIn01.mag to AnIn08.mag Analog Inputs (AI401 to AI408)—Slot D
c
AINEGGIO23 AnIn01.mag to AnIn08.mag Analog Inputs (AI501 to AI508)—Slot E
c
Relay Word Bits
INAGGIO1 Ind01.stVal to Ind02.stVal Digital Inputs (IN101 to IN102)—Slot A
OUTAGGIO2 Ind01.stVal to Ind03.stVal Digital Outputs (OUT101 to OUT103)—Slot A
SVGGIO3 Ind01.stVal to Ind32.stVal SELOGIC Variables (SV01 to SV32)
d
SVTGGIO4 Ind01.stVal to Ind32.stVal SELOGIC Variable Timers (SV01T to SV32T)
d
LTGGIO5 Ind01.stVal to Ind32.stVal Latch Bits (LT01 to LT32)
e
TLEDGGIO6 Ind01.stVal to Ind08.stVal Target LEDs (ENABLED, TRIP_LED, TLED_01 to TLED_06)
PBLEDGGIO7 Ind01.stVal to Ind08.stVal Pushbutton LEDs (PB1A_LED to PB4B_LED)
RMBAGGIO8 Ind01.stVal to Ind08.stVal Receive M
IRRORED BITS (RMB1A to RMB8A)
TMBAGGIO9 Ind01.stVal to Ind08.stVal Transmit M
IRRORED BITS (TMB1A to TMB8A)
RMBBGGIO10 Ind01.stVal to Ind08.stVal Receive M
IRRORED BITS (RMB1B to RMB8B)
TMBBGGIO11 Ind01.stVal to Ind08.stVal Transmit M
IRRORED BITS (TMB1B to TMB8B)
INCGGIO13 Ind01.stVal to Ind08.stVal Digital Inputs (IN301 to IN308)—Slot C
c
OUTCGGIO14 Ind01.stVal to Ind04.stVal Digital Outputs (OUT301 to OUT304)—Slot C
c
INDGGIO15 Ind01.stVal to Ind08.stVal Digital Inputs (IN401 to IN408)—Slot D
c
OUTDGGIO16 Ind01.stVal to Ind04.stVal Digital Outputs (OUT401 to OUT404)—Slot D
c
INEGGIO17 Ind01.stVal to Ind08.stVal Digital Inputs (IN501 to IN508)—Slot E
c
OUTEGGIO18 Ind01.stVal to Ind04.stVal Digital Outputs (OUT501 to OUT504)—Slot E
c
VBGGIO19 Ind001.stVal to Ind128.stVal Virtual Bits (VB001 to VB128)
a
Active data depends on the EMV setting.
b
Active data depends on the ESC setting.
c
Active data only if an I/O card is installed in the slot.
d
Active data depends on the ESV setting.
e
Active data depends on the ELT setting.
