F.23
Date Code 20100129 Instruction Manual SEL-751A Relay
IEC 61850 Communications
Logical Nodes
METMSTA1 MaxPhV.phsB.mag B-phase voltage maximum magnitude
a
METMSTA1 MaxPhV.phsC.mag C-phase voltage maximum magnitude
a
METMSTA1 MinPhV.phsA.mag A-phase voltage minimum magnitude
a
METMSTA1 MinPhV.phsB.mag B-phase voltage minimum magnitude
a
METMSTA1 MinPhV.phsC.mag C-phase voltage minimum magnitude
a
METMSTA1 MaxP2PV.phsAB.mag AB-phase voltage maximum magnitude
a
METMSTA1 MaxP2PV.phsBC.mag BC-phase voltage maximum magnitude
a
METMSTA1 MaxP2PV.phsCA.mag CA-phase voltage maximum magnitude
a
METMSTA1 MinP2PV.phsAB.mag AB-phase voltage minimum magnitude
a
METMSTA1 MinP2PV.phsBC.mag BC-phase voltage minimum magnitude
a
METMSTA1 MinP2PV.phsCA.mag CA-phase voltage minimum magnitude
a
METMSTA1 MaxVA.mag 3-Phase VA maximum magnitude
a
METMSTA1 MinVA.mag 3-Phase VA minimum magnitude
a
METMSTA1 MaxW.mag 3-Phase W maximum magnitude
a
METMSTA1 MinW.mag 3-Phase W minimum magnitude
a
METMSTA1 MaxVAr.mag 3-Phase VAr maximum magnitude
a
METMSTA1 MinVAr.mag 3-Phase VAr minimum magnitude
a
Demand Metering Statistics
METMDST1 DmdA.phsA.mag Demand, Phase A Current
c
METMDST1 DmdA.phsB.mag Demand, Phase B Current
c
METMDST1 DmdA.phsC.mag Demand, Phase C Current
c
METMDST1 DmdA.res.mag Demand, Current, Residual
c
METMDST1 DmdA.nseq.mag Demand, Current, Negative Sequence
c
METMDST1 PkDmdA.phsA.mag Peak Demand, Phase A Current
c
METMDST1 PkDmdA.phsB.mag Peak Demand, Phase B Current
c
METMDST1 PkDmdA.phsC.mag Peak Demand, Phase C Current
c
METMDST1 PkDmdA.res.mag Peak Demand, Current, Residual
c
METMDST1 PkDmdA.nseq.mag Peak Demand, Current, Negative Sequence
c
METMDST1 SupWh.mag Energy, Real (MWh)—Supply direction flows toward bus-
bar
c
METMDST1 SupVArh.mag Energy, Reactive (MVArh) —Supply direction toward bus-
bar
c
METMDST1 DmdWh.mag Energy, Real (MWh)—Demand direction flows away from
busbar
c
METMDST1 DmdVArh.mag Energy, Reactive (MVArh)—Demand direction away from
busbar
c
a
Valid data only if either PT card (AVI) or differential PT/CT card (3AVI/3ACI) is installed.
b
Valid data depends on E49RTD and RTD1LOC—RTD12LOC settings.
c
Valid data only if a premium voltage option card (5AVI or 3 AVI/4 AFDI) is installed.
Table F.13 Logical Device: MET (Metering) (Sheet 3 of 3)
Logical Node Measurand Comment
