Date Code 20100129 Instruction Manual SEL-751A Relay
Section 3
PC Software
Overview
SEL provides many PC software solutions (applications) to support the
SEL-751A and other SEL devices. Table 3.1 lists SEL-751A software
solutions.
This section describes how to get started with the SEL-751A and
ACSELERATOR QuickSet SEL-5030 software. ACSELERATOR QuickSet is a
powerful setting, event analysis, and measurement tool that aids in setting,
applying, and using the SEL-751A. Tab l e 3. 2 shows the suite of
ACSELERATOR QuickSet applications provided for the SEL-751A.
Table 3.1 SEL Software Solutions
Part Number Product Name Description
SEL-5010 SEL-5010 Relay Assistant Software Manages a connection directory and settings of multi-
ple devices
SEL-5030
ACSELERATOR QuickSet
®
SEL-5030 Software See Table 3.2
SEL-5031
ACSELERATOR QuickSet
Designer
®
SEL-5031 Software Customizes SEL-751A settings for specific applica-
tions
SEL-5032
ACSELERATOR Architect SEL-5032 Software Configures IEC 61850 communications
SEL-5040
ACSELERATOR Report Server SEL-5040 Software Automatically retrieves, files, and summarizes reports
SEL-5601
ACSELERATOR Analytic Assistant SEL-5601 Software Converts SEL Compressed ASCII event report files to
oscillography
SEL-5801 SEL-5801 Cable Selector Software Selects the proper SEL cables for your application
Ta b le 3 .2 ACSELERATOR QuickSet SEL-5030 Software
Terminal Provides a direct connection to the SEL device. Use this communication method to inter-
face directly with the device.
Rules-Based Settings Editor Provides on-line or off-line relay settings that include interdependency checks. Use this
feature to create and manage settings for multiple relays in a database.
Event Analysis Provides oscillography and other event analysis tools.
Meter and Control Provides Human Machine Interface (HMI) for metering and control features.
Setting Database Management
ACSELERATOR QuickSet uses a database to manage the settings of multiple devices.
Help Provides general
ACSELERATOR QuickSet and relay-specific ACSELERATOR QuickSet
context help.
