SEL-751A Settings Sheets
Group Settings (SET Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
SYNCPH PHASE (VAB, VBC, VCA, 0, 30, 60, 90, 120, 150, 180,
210, 240, 270, 300, 330 deg lag VAB)
(Hidden if E25 := N)
(Hidden if DELTA_Y := WYE)
SYNCPH :=
BRKR CLOSE TIME (OFF, 1–1000 ms)
(Hidden if E25 := N) TCLOSD :=
BLK SYNCH CHECK (SEL
OGIC) (Hidden if E25 := N) BSYNCH :=
Power Factor
(Hidden if Voltage Card Option Not Included)
PF LAG TRIP LEVL (OFF, 0.05–0.99) 55LGTP :=
PF LD TRIP LEVEL (OFF, 0.05–0.99)
55LDTP :=
PF TRIP DELAY (1–240 sec)
(Hidden if both 55LDTP and 55LGTP := OFF)
55TD :=
PF LAG WARN LEVL (OFF, 0.05–0.99)
55LGAP :=
PF LD WARN LEVEL (OFF, 0.05–0.99)
55LDAP :=
PF WARN DELAY (1–240 sec)
(Hidden if both 55LDAP and 55LGAP := OFF)
55AD :=
PF ARMING DELAY (0–5000 sec)
(Hidden if all 55LGTP, 55LDTP, 55LGAP, and 55LDAP := OFF)
55DLY :=
Frequency
FREQ1 TRIP LEVEL (OFF, 20.00–70.00 Hz) 81D1TP :=
FREQ1 TRIP DELAY (0.00–240.00 sec)
(Hidden if 81D1TP := OFF)
81D1TD :=
FREQ2 TRIP LEVEL (OFF, 20.00–70.00 Hz)
81D2TP :=
FREQ2 TRIP DELAY (0.00–240.00 sec)
(Hidden if 81D2TP := OFF)
81D2TD :=
FREQ3 TRIP LEVEL (OFF, 20.00–70.00 Hz)
81D3TP :=
FREQ3 TRIP DELAY (0.00–240.00 sec)
(Hidden if 81D3TP := OFF)
81D3TD :=
FREQ4 TRIP LEVEL (OFF, 20.00–70.00 Hz)
81D4TP :=
FREQ4 TRIP DELAY (0.00–240.00 sec)
(
Hidden if 81D4TP := OFF)
81D4TD :=
FREQ5 TRIP LEVEL (OFF, 20.00–70.00 Hz)
81D5TP :=
FREQ5 TRIP DELAY (0.00–240.00 sec)
(
Hidden if 81D5TP := OFF)
81D5TD :=
FREQ6 TRIP LEVEL (OFF, 20.00–70.00 Hz)
81D6TP :=
FREQ6 TRIP DELAY (0.00–240.00 sec)
(
Hidden if 81D6TP := OFF)
81D6TD :=
