F.10
SEL-751A Relay Instruction Manual Date Code 20100129
IEC 61850 Communications
IEC 61850 Configuration
Incoming GOOSE messages are processed in accordance with the following
constraints:
➤ The user can configure the SEL-751A to subscribe to as many
as 16 incoming GOOSE messages.
The SEL-751A will recognize incoming GOOSE messages as
valid based on the following content. Any GOOSE message
that fails these checks shall be rejected.
➢ Source broadcast MAC address
➢ Dataset Reference
➢ Application ID
➢ GOOSE Control Reference
➤ Rejection of all DA contained in an incoming GOOSE, based
on the accumulation of the following error indications created
by inspection of the received GOOSE:
➢ Configuration Mismatch: the configuration number of
the incoming GOOSE changes.
➢ Needs Commissioning: this Boolean parameter of the
incoming GOOSE is true.
➢ Test Mo de: this Boolean parameter of the incoming
GOOSE is true.
➢ Decode Error: the format of the incoming GOOSE is
not as configured.
➤ The SEL-751A will discard incoming GOOSE under the
following conditions:
➢ after a permanent (latching) self-test failure
➢ when EGSE is set to No
Link-layered priority tagging and virtual LAN is supported as described in
Annex C of IEC 61850-8-1:2004(E).
IEC 61850 Configuration
Settings
Table F.6 lists IEC 61850 settings. IEC 61850 settings are only available if
your device includes the optional IEC 61850 protocol.
Configure all other IEC 61850 settings, including subscriptions to incoming
GOOSE messages, with
ACSELERATOR Architect software.
Table F.6 IEC 61850 Settings
Label Description Range Default
E61850 IEC 61850 interface enable Y, N N
EGSE Outgoing IEC 61850 GSE message enable Y
a
, N
a
Requires E61850 set to Y to send IEC 61850 GSE messages.
N
