SEL Communications Processors
SEL Communications Processor Example
Relay Metering Data
Table C.8 shows the list of meter data available in the SEL communications
processor and the location and data type for the memory areas within D1
(Data Region 1). The type field indicates the data type and size. The int type is
a 16-bit integer. The float type is a 32-bit IEEE floating point number. Use the
VIE n:D1 command to view these data.
Table C.8 Communications Processor METER Region Map
Item Starting Address Type
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h int[2]
MONTH 2004h char
DATE 2005h char
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
IA 200Bh float
IB 200Dh float
IC 200Fh float
IN 2011h float
IG 2013h float
UBI 2015h float
VAB 2017h float
VBC 2019h float
VCA 201Bh float
* 201Dh float
VS 201Fh float
UBV 2021h float
P 2023h float
Q 2025h float
S 2027h float
PF 2029h float
FREQ 202Bh float
VDC 202Dh float
WDG 202Fh float
BRG 2031h float
AMB 2033h float
OTH 2035h float
