The following figure shows the LED location specific to the SEL-751A (see

Figure 2.10 for the complete rear-panel drawing).

SEL-751A LED Locations

i4333a

Fiber-Optic Serial Port LED

Arc-Flash Detection LEDs

for Self-Test

Fiber-Optic Ethernet

Port LEDs

LED Safety Warnings and Precautions

➤ Do not look into the end of an optical cable connected to an

optical output.

➤ Do not look into the fiber ports/connectors.

➤ Do not perform any procedures or adjustments that are not

described in this manual.

➤ During installation, maintenance, or testing of the optical

ports only use test equipment classified as Class 1 laser

products.

➤ Incorporated components such as transceivers and laser/LED

emitters are not user serviceable. Units must be returned to

SEL for repair or replacement.
