8.10
SEL-751A Relay Instruction Manual Date Code 20100129
Front-Panel Operations
Human-Machine Interface
Set/Show Menu
Select the Set/Show menu item on the MAIN menu. The Set/Show menu is used
to view or modify the settings (
Global, Group, and Port), Active Group,
Date, and Time. Note that modifying the settings requires Level 2 access.
Figure 8.20 MAIN Menu and SET/SHOW Submenu
Each settings class (Global, Group, and Port) includes headings that create
subgroups of associated settings as shown in the following illustration. Select
the heading that contains the setting of interest, and then navigate to the
particular setting. View or edit the setting by pressing the {ENT} pushbutton.
For text settings, use the four navigation pushbuttons to scroll through the
available alphanumeric and special character settings matrix. For numeric
settings, use the {Left Arrow} and {Right Arrow} pushbuttons to select the digit to
change and the {Up Arrow} and {Down Arrow} pushbuttons to change the value.
Press the {ENT} pushbutton to enter the new setting.
Setting changes can also be made using
ACSELERATOR QuickSet
®
SEL-5030
Software or ASCII SET commands via a communications port.
SET/SHOW
Global
Group
Port
Active Group
Date
Time
Password
(Set/Show Selected)
MAIN
Meter
Events
Targets
Control
Set/Show
Status
Breaker
