Sel 751A - Appendix J: Relay Word Bits Overview

J.2
SEL-751A Relay Instruction Manual Date Code 20100129
Relay Word Bits
Overview
16
OUT401 OUT402 OUT403 OUT404 OUT501 OUT502 OUT503 OUT504
17
IN101 IN102 * * * * * *
18
IN301 IN302 IN303 IN304 IN305 IN306 IN307 IN308
19
IN401 IN402 IN403 IN404 IN405 IN406 IN407 IN408
20
IN501 IN502 IN503 IN504 IN505 IN506 IN507 IN508
21
WDGALRM WDGTRIP BRGALRM BRGTRIP RSTENRGY RSTMXMN RSTDEM RSTPKDEM
22
RTDFLT RTDIN TRGTR 3PWR1P 3PWR2P DSABLSET RSTTRGT HALARM
23
RTD1A RTD1T RTD2A RTD2T RTD3A RTD3T RTD4A RTD4T
24
RTD5A RTD5T RTD6A RTD6T RTD7A RTD7T RTD8A RTD8T
25
RTD9A RTD9T RTD10A RTD10T RTD11A RTD11T RTD12A RTD12T
26
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
27
CLOSE CF RCSF OPTMN RSTMN LINKFAIL PASE L PBSEL
28
SG1 SG2 SG3 * * DI_C DI_B DI_A
29
CC OC * ER ULTRIP TR FREQTRK PMTRIG
30
DNAUX1 DNAUX2 DNAUX3 DNAUX4 DNAUX5 DNAUX6 DNAUX7 DNAUX8
31
DNAUX9 DNAUX10 DNAUX11 RELAY_EN TREA1 TREA2 TREA3 TREA4
32
PB01 PB02 PB03 PB04 PB01_PUL PB02_PUL PB03_PUL PB04_PUL
33
PB1A_LED PB1B_LED PB2A_LED PB2B_LED PB3A_LED PB3B_LED PB4A_LED PB4B_LED
34
CL ULCL T01_LED T02_LED T03_LED T04_LED T05_LED T06_LED
35
LB01 LB02 LB03 LB04 LB05 LB06 LB07 LB08
36
LB09 LB10 LB11 LB12 LB13 LB14 LB15 LB16
37
LB17 LB18 LB19 LB20 LB21 LB22 LB23 LB24
38
LB25 LB26 LB27 LB28 LB29 LB30 LB31 LB32
39
RB01 RB02 RB03 RB04 RB05 RB06 RB07 RB08
40
RB09 RB10 RB11 RB12 RB13 RB14 RB15 RB16
41
RB17 RB18 RB19 RB20 RB21 RB22 RB23 RB24
42
RB25 RB26 RB27 RB28 RB29 RB30 RB31 RB32
43
SV01 SV02 SV03 SV04 SV05 SV06 SV07 SV08
44
SV01T SV02T SV03T SV04T SV05T SV06T SV07T SV08T
45
SV09 SV10 SV11 SV12 SV13 SV14 SV15 SV16
46
SV09T SV10T SV11T SV12T SV13T SV14T SV15T SV16T
47
SV17 SV18 SV19 SV20 SV21 SV22 SV23 SV24
48
SV17T SV18T SV19T SV20T SV21T SV22T SV23T SV24T
49
SV25 SV26 SV27 SV28 SV29 SV30 SV31 SV32
50
SV25T SV26T SV27T SV28T SV29T SV30T SV31T SV32T
51
LT01 LT 02 LT03 LT 04 LT05 LT06 LT07 LT 08
52
LT09 LT10 LT11 LT12 LT13 LT14 LT15 LT16
53
LT17 LT 18 LT19 LT 20 LT21 LT22 LT23 LT 24
54
LT25 LT26 LT27 LT28 LT29 LT30 LT31 LT32
55
SC01QU SC02QU SC03QU SC04QU SC05QU SC06QU SC07QU SC08QU
Ta b le J . 1 S E L-7 5 1 A Re l ay Wo rd B i t s (Sheet 2 of 4)
Bit/
Row
Relay Word Bits
7 6 5 4 3 2 1 0
