D.26
SEL-751A Relay Instruction Manual Date Code 20100129
DNP3 Communications
DNP3 Documentation
Default Data Map
The default data map is an automatically generated subset of the reference
map. All data maps are initialized to the default values, based on the
SEL-751A part number. Table D.1 3 shows the SEL-751A default data map. If
the default maps are not appropriate, you can also use the custom DNP
mapping commands SET DNP and SHOW DNP to create the map required
for your application.
Analog Outputs
40, 41 GROUP Active Settings Group
NOOP No operation, no error
Table D.12 DNP3 Reference Data Map (Sheet 2 of 2)
Object. Labels Description
NOTE: Although not shown as part
of the reference maps you may use
any Relay Word bit label when
creating custom maps.
Table D.13 DNP3 Default Data Map
Object Default Index Point Label
01, 02 0 ENABLED
1 TRIP_LED
2 TLED_01
3 TLED_02
4 TLED_03
5 TLED_04
6 TLED_05
7 TLED_06
8STFAIL
9 STSET
10 IN101
11 IN102
12–99 A portion of these binary inputs can have default values as
described in Binary Inputs on page D.27. Outside that
scope, they contain the value NA.
10, 12 0–31 RB01–RB32 Remote Bits
20, 22 0–31 NA
30, 32, 34 0 IA_MAG
1IB_MAG
2IC_MAG
3IG_MAG
4IN_MAG
5IAV
63I2
7FREQ
8–99 A portion of these analog inputs can have default values as
described in Analog Inputs on page D.27. Outside that
scope, they contain the value NA.
40, 41 0–31 NA
