F.25
Date Code 20100129 Instruction Manual SEL-751A Relay
IEC 61850 Communications
Protocol Implementation Conformance Statement
Protocol Implementation Conformance Statement
The following tables are as shown in the IEC 61850 standard, Part 8-1,
Section 24. Note that since the standard explicitly dictates which services and
functions must be implemented to achieve conformance, only the optional
services and functions are listed.
Refer to the ACSI Conformance statements in the Reference Manual for
information on the supported services.
MMS Conformance
The Manufacturing Messaging Specification (MMS) stack provides the basis
for many IEC 61850 Protocol services. Table F.18 defines the service support
requirement and restrictions of the MMS services in the SEL-700 series
products supporting IEC 61850. Generally, only those services whose
implementation is not mandatory are shown. Refer to the IEC 61850 standard
Part 8-1 for more information.
Table F.16 PICS for A-Profile Support
Profile Client Server Value/Comment
A1 Client/Server N Y
A2 GOOSE/GSE management Y Y Only GOOSE, not GSSE
Management
A3 GSSE N N
A4 Time Sync N N
Table F.17 PICS for T-Profile Support
Profile Client Server Value/Comment
T1 TCP/IP N Y
T2 OSI N N
T3 GOOSE/GSE Y Y Only GOOSE, Not GSSE
T4 GSSE N N
T5 Time Sync N N
Table F.18 MMS Service Supported Conformance (Sheet 1 of 3)
MMS Service Supported CBB Client-CR Supported Server-CR Supported
status Y
getNameList Y
identify Y
rename
read Y
write Y
getVariableAccessAttributes Y
defineNamedVariable
defineScatteredAccess
getScatteredAccessAttributes
deleteVariableAccess
defineNamedVariableList
