1.18
SEL-751A Relay Instruction Manual Date Code 20100129
Introduction and Specifications
Getting Started
=>STA <Enter>
SEL-751A Date: 08/13/2009 Time: 20:29:29
FEEDER RELAY Time Source: External
Serial Num = 000000000000000
FID = SEL-751A-X402-V0-Z005003-D20090803 CID = CD05
PART NUM = 751A01BA30X7386163X
SELF TESTS (W=Warn)
FPGA GPSB HMI RAM ROM CR_RAM NON_VOL CLOCK CID_FILE +0.9V +1.2V
OK OK OK OK OK OK OK OK OK 0.90 1.19
+1.5V +1.8V +2.5V +3.3V +3.75V +5.0V -1.25V -5.0V BATT
1.49 1.81 2.49 3.33 3.76 4.97 -1.25 -4.91 3.07
Option Cards
CARD_C CARD_D CARD_E CURRENT
OK OK OK OK
DeviceNet
DN_MAC_ID ASA DN_RATE DN_STATUS
3 1a0d c1e9h 500kbps 0000 0000
Offsets
IA IB IC IN VA VB VC VS
OK OK OK OK OK OK OK OK
Relay Enabled
=>
Figure 1.4 STA Command Response—Communications Card/DeviceNet
Protocol
Table 7.47 provides the definition of each status report designator and
Table 10.7 shows all the self-tests performed by the relay. The beginning of
the status report printout (see Figure 1.3) contains the relay serial number,
firmware identification string (FID), and checksum string (CID). These strings
uniquely identify the relay and the version of the operating firmware.
Setting the
Date and Time
DAT (Date Command)
Viewing the Date
Type DAT <Enter> at the prompt to view the date stored in the SEL-751A. If
the date stored in the relay is July 29, 2003, and the DATE_F setting is MDY,
the relay will reply:
7/29/2003
If the DATE_F setting is YMD, the relay will reply:
2003/7/29
If the DATE_F setting is DMY, the relay will reply:
29/7/2003
Changing the Date
Type DAT followed by the correct date at the prompt to change the date stored
in the relay. For example, to change the date to May 2, 2003 (DATE_F =
MDY), enter the following at the action prompt:
DAT 5/2/03
You can separate the month, day, and year parameters with spaces, commas,
slashes, colons, and semicolons.
