Sel 751A - Table E.9 03 H Read Holding Register Command; Table E.10 Responses to 03 H Read Holding Register Query Errors; Table E.11 04 H Read Input Register Command

E.9
Date Code 20100129 Instruction Manual SEL-751A Relay
Modbus RTU Communications
Communications Protocol
The relay responses to errors in the query are shown in Table E .10 .
04h Read Input
Register Command
Use function code 04h to read directly from the Modbus Register Map shown
in Table E.32. You can read a maximum of 125 registers at once with this
function code. Most masters use 4X references with this function code. If you
are accustomed to 4X references with this function code, for five-digit
addressing, add 40001 to the standard database address.
Table E.9 03h Read Holding Register Command
Bytes Field
Requests from the master must have the following format:
1 byte Slave Address
1 byte Function Code (03h)
2 bytes Starting Register Address
2 bytes Number of Registers to Read
2 bytes CRC-16
A successful response from the slave will have the following format:
1 byte Slave Address
1 byte Function Code (03h)
1 byte Bytes of data (n)
n bytes Data (2–250)
2 bytes CRC-16
Table E.10 Responses to 03h Read Holding Register Query Errors
Error Error Code Returned
Communication
Counter Increments
Illegal register to read Illegal Data Address (02h) Invalid Address
Illegal number of registers to read Illegal Data Value (03h) Illegal Register
Format error Illegal Data Value (03h) Bad Packet Format
Table E.11 04h Read Input Register Command (Sheet 1 of 2)
Bytes Field
Requests from the master must have the following format:
1 byte Slave Address
1 byte Function Code (04h)
2 bytes Starting Register Address
2 bytes Number of Registers to Read
2 bytes CRC-16
