SEL-751A Settings Sheets
Global Settings (SET G Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
MESSENGER POINT MP27 TEXT (148 characters) MPTX27 :=
MESSENGER POINT MP28 TRIGGER (
Off, 1 Relay Word bit) MPTR28 :=
MESSENGER POINT MP28 AQ (
None, 1 analog quantity) MPAQ28 :=
MESSENGER POINT MP28 TEXT (
148 characters) MPTX28 :=
MESSENGER POINT MP29 TRIGGER (
Off, 1 Relay Word bit) MPTR29 :=
MESSENGER POINT MP29 AQ (
None, 1 analog quantity) MPAQ29 :=
MESSENGER POINT MP29 TEXT (
148 characters) MPTX29 :=
MESSENGER POINT MP30 TRIGGER (
Off, 1 Relay Word bit) MPTR30 :=
MESSENGER POINT MP30 AQ (
None, 1 analog quantity) MPAQ30 :=
MESSENGER POINT MP30 TEXT (
148 characters) MPTX30 :=
MESSENGER POINT MP31 TRIGGER (
Off, 1 Relay Word bit) MPTR31 :=
MESSENGER POINT MP31 AQ (
None, 1 analog quantity) MPAQ31 :=
MESSENGER POINT MP31 TEXT (
148 characters) MPTX31 :=
MESSENGER POINT MP32 TRIGGER (
Off, 1 Relay Word bit) MPTR32 :=
MESSENGER POINT MP32 AQ (
None, 1 analog quantity) MPAQ32 :=
MESSENGER POINT MP32 TEXT (
148 characters) MPTX32 :=
Group Selection
GRP CHG DELAY (0–400 sec) TGR :=
SELECT GROUP1 (SEL
OGIC) SS1 :=
SELECT GROUP2 (SEL
OGIC) SS2 :=
SELECT GROUP3 (SEL
OGIC) SS3 :=
Phasor Measurement (PMU)
EN SYNCHRO PHASOR (Y, N) (All subsequent PMU settings
Hidden if EPMU :=N
)
EPMU :=
MESSAGES PER SEC (1, 2, 5, 10)
MRATE :=
STATION NAME (16 characters)
PMSTN :=
PMU HARDWARE ID (1–65534)
PMID :=
VOLTAGE DATA SET (V1, ALL, NA) (
Hidden if no voltages) PHDATAV :=
VOLT COMP ANGLE (–179.99 to 180.00 deg)
(
Hidden if PHDATAV := NA)
VCOMP :=
CURRENT DATA SET (I1, ALL, NA)
PHDATAI :=
CURRENT COMP ANGLE (–179.99 to 180.00
deg)(
Hidden if PHDATAI := NA)
ICOMP :=
NUM ANALOG (0–4)
NUMANA :=
NUM 16-BIT DIGTAL (0, 1)
NUMDSW :=
