Sel 751A - Mirrored Bits Protocol

Date _______________
Date Code 20100129 Instruction Manual SEL-751A Relay
SET.43
of 68
SEL-751A Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Number of Events to Transmit On (1–200)
(HiddenifUNSOL1:=N)
NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(HiddenifUNSOL1:=N)
AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10)
(HiddenifUNSOL1:=N)
URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(HiddenifUNSOL1:=N)
UTIMEO1 :=
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, or MOD)
MB Transmit Identifier (1–4) TXID :=
MB Receive Identifier (1–4)
RXID :=
MB RX Bad Pickup Time (0–10000 seconds)
RBADPU :=
PPM MB Channel Bad Pickup (1–10000)
CBADPU :=
MB Receive Default State (8 characters)
RXDFLT :=
RMB1 Pickup Debounce Messages (1–8)
RMB1PU :=
RMB1 Dropout Debounce Messages (1–8)
RMB1DO :=
RMB2 Pickup Debounce Messages (1–8)
RMB2PU :=
RMB2 Dropout Debounce Messages (1–8)
RMB2DO :=
RMB3 Pickup Debounce Messages (1–8)
RMB3PU :=
RMB3 Dropout Debounce Messages (1–8)
RMB3DO :=
RMB4 Pickup Debounce Messages (1–8)
RMB4PU :=
RMB4 Dropout Debounce Messages (1–8)
RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
PORT 3 (EIA-232/485 Port in Slot B)
PROTOCOL (SEL, DNP, MOD, EVMSG, PMU, MBA, MBB,
MB8A, MB8B, MBTA, MBTB)
PROTO :=
