SET.44
of 68
SEL-751A Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
Communications
SPEED (300, 1200, 2400, 4800, 9600, 19200, 38400 bps) SPEED :=
DATA BITS (7, 8 bits)
(Hidden if PROTO := DNP, PMU, MOD,
EVMSG, or MB_)
BITS :=
PARITY (O, E, N)
(Hidden if PROTO := EVMSG, PMU, or MB_) PARITY :=
STOP BITS (1, 2 bits)
(Hidden if PROTO := MOD, EVMSG, or
MB_)
STOP :=
PORT TIME-OUT (0–30 min)
(Hidden if PROTO := MOD, PMU,
EVMSG, or MB_)
T_OUT :=
HDWR HANDSHAKING (Y, N)
(Hidden if COMMINF :=485 or
PROTO := MOD, DNP, EVMSG, or MB_)
RTSCTS :=
SEND AUTOMESSAGE (Y, N)
(Hidden if PROTO := MOD, DNP,
PMU, EVMSG, or MB_)
AUTO :=
FAST OP MESSAGES (Y, N)
(Hidden if PROTO := MOD, DNP,
PMU, EVMSG, or MB_)
FAS TOP :=
Modbus
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL,
EVMSG, or MB_)
SLAVEID :=
DNP3 Protocol
(Hidden if PROTO := SEL, EVMSG, MB, PMU or MOD.)
DNP Address (0–65519) DNPADR :=
DNP Address to Report to (0–65519)
REPADR1 :=
DNP Map (1–3)
DNPMAP1 :=
Analog Input Default Variation (1–6)
DVARAI1 :=
Class for Binary Event Data (0–3)
ECLASSB1 :=
Class for Counter Event Data (0–3)
ECLASSC1 :=
Class for Analog Event Data (0–3)
ECLASSA1 :=
Currents Scaling Decimal Places (0–3)
DECPLA1 :=
Voltages Scaling Decimal Places (0–3)
DECPLV1 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM1 :=
Amps Reporting Deadband Counts (0–32767)
(HiddenifECLASSA1:=0)
ANADBA1 :=
Volts Reporting Deadband Counts (0–32767)
(HiddenifECLASSA1:=0)
ANADBV1 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0)
ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO1 :=
