Sel 751A - Input Debounce Settings (Slot D); Input Debounce Settings (Slot E)

SET.36
of 68
SEL-751A Settings Sheets
Global Settings (SET G Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
Input Debounce Settings (Slot D)
(Hidden If Input Option Not Included)
IN401 Debounce (AC, 0–65000 ms) IN401D :=
IN402 Debounce (AC, 0–65000 ms)
IN402D :=
IN403 Debounce (AC, 0–65000 ms)
IN403D :=
IN404 Debounce (AC, 0–65000 ms)
IN404D :=
IN405 Debounce (AC, 0–65000 ms)
IN405D :=
IN406 Debounce (AC, 0–65000 ms)
IN406D :=
IN407 Debounce (AC, 0–65000 ms)
IN407D :=
IN408 Debounce (AC, 0–65000 ms)
IN408D :=
Input Debounce Settings (Slot E)
(Hidden If Input Option Not Included)
IN501 Debounce (AC, 0–65000 ms) IN501D :=
IN502 Debounce (AC, 0–65000 ms)
IN502D :=
IN503 Debounce (AC, 0–65000 ms)
IN503D :=
IN504 Debounce (AC, 0–65000 ms)
IN504D :=
IN505 Debounce (AC, 0–65000 ms)
IN505D :=
IN506 Debounce (AC, 0–65000 ms)
IN506D :=
IN507 Debounce (AC, 0–65000 ms)
IN507D :=
IN508 Debounce (AC, 0–65000 ms)
IN508D :=
Breaker Monitor Settings
BREAKER MONITOR (Y,N) (All subsequent settings
Hidden if EBMON :=N)
EBMON :=
CL/OPN OPS SETPT 1 (0–65000)
COSP1 :=
CL/OPN OPS SETPT 2 (0–65000)
COSP2 :=
CL/OPN OPS SETPT 3 (0–65000)
COSP3 :=
kA PRI INTERRPTD 1 (0.10–999.00)
KASP1 :=
kA PRI INTERRPTD 2 (0.10–999.00)
KASP2 :=
kA PRI INTERRPTD 3 (0.10–999.00)
KASP3 :=
Control Breaker Monitor (SEL
OGIC) BKMON :=
Data Reset
RESET TARGETS (SELOGIC) RSTTRGT :=
RESET ENERGY (SEL
OGIC) RSTENRGY:=
