SEL-751A Settings Sheets
Global Settings (SET G Command)
AOx03 HI OUT VAL (–20.480 to +20.480 mA) AOx03H :=
If AOx03TYP = V
AOx03 LO OUT VAL (–10.240 to +10.240 V)
AOx03L :=
AOx03 HI OUT VAL (–10.240 to +10.240 V)
AOx03H :=
AO x 04
AOx04 ANALOG QTY (Off, 1 analog quantity) AOx04AQ :=
AOx04 TYPE (I, V)
AOx04TYP :=
AOx04 AQTY LOW (–2147483647 to +2147483647)
AOx04AQL :=
AOx04 AQTY HI (–2147483647 to +2147483647)
AOx04AQH :=
If AOx04TYP = I
AOx04 LO OUT VAL (–20.480 to +20.480 mA)
AOx04L :=
AOx04 HI OUT VAL (–20.480 to +20.480 mA)
AOx04H :=
If AOx04TYP = V
AOx04 LO OUT VAL (–10.240 to +10.240 V)
AOx04L :=
AOx04 HI OUT VAL (–10.240 to +10.240 V)
AOx04H :=
Station DC Battery Monitor
(Hidden if Voltage Option xx73xx or xx74xx not included, see Table 1.1 )
DC UNDER VOLT PU (OFF, 20.00–300.00 Vdc) DCLOP :=
DC OVER VOLT PU (OFF, 20.00–300.00 Vdc)
DCHIP :=
Input Debounce Settings (Base Unit)
IN101 Debounce (AC, 0–65000 ms) IN101D :=
IN102 Debounce (AC, 0–65000 ms)
IN102D :=
Input Debounce Settings (Slot C)
(Hidden If Input Option Not Included)
IN301 Debounce (AC, 0–65000 ms) IN301D :=
IN302 Debounce (AC, 0–65000 ms)
IN302D :=
IN303 Debounce (AC, 0–65000 ms)
IN303D :=
IN304 Debounce (AC, 0–65000 ms)
IN304D :=
IN305 Debounce (AC, 0–65000 ms)
IN305D :=
IN306 Debounce (AC, 0–65000 ms)
IN306D :=
IN307 Debounce (AC, 0–65000 ms)
IN307D :=
IN308 Debounce (AC, 0–65000 ms)
IN308D :=
