SEL-751A Settings Sheets
Global Settings (SET G Command)
SEL-751A Relay Instruction Manual Date Code 20100129
Date________________
AIx08 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx08LW2 :=
AIx08 LO ALARM (OFF, –99999.000 to +99999.000)
AIx08LAL :=
AIx08 HI WARN L1 (OFF, –99999.000 to +99999.000)
AIx08HW1 :=
AIx08 HI WARN L2 (OFF, –99999.000 to +99999.000)
AIx08HW2 :=
AIx08 HI ALARM (OFF, –99999.000 to +99999.000)
AIx08HAL :=
AO x 01
AOx01 ANALOG QTY (Off, 1 analog quantity) AOx01AQ :=
AOx01 TYPE (I, V)
AOx01TYP :=
AOx01 AQTY LOW (–2147483647 to +2147483647)
AOx01AQL :=
AOx01 AQTY HI (–2147483647 to +2147483647)
AOx01AQH :=
If AOx01TYP = I
AOx01 LO OUT VAL (–20.480 to +20.480 mA)
AOx01L :=
AOx01 HI OUT VAL (–20.480 to +20.480 mA)
AOx01H :=
If AOx01TYP = V
AOx01 LO OUT VAL (–10.240 to +10.240 V)
AOx01L :=
AOx01 HI OUT VAL (–10.240 to +10.240 V)
AOx01H :=
AO x 02
AOx02 ANALOG QTY (Off, 1 analog quantity) AOx02AQ :=
AOx02 TYPE (I, V)
AOx02TYP :=
AOx02 AQTY LOW (–2147483647 to +2147483647)
AOx02AQL :=
AOx02 AQTY HI (–2147483647 to +2147483647)
AOx02AQH :=
If AOx02TYP = I
AOx02 LO OUT VAL (–20.480 to +20.480 mA)
AOx02L :=
AOx02 HI OUT VAL (–20.480 to +20.480 mA)
AOx02H :=
If AOx02TYP = V
AOx02 LO OUT VAL (–10.240 to +10.240 V)
AOx02L :=
AOx02 HI OUT VAL (–10.240 to +10.240 V)
AOx02H :=
AO x 03
AOx03 ANALOG QTY (Off, 1 analog quantity) AOx03AQ :=
AOx03 TYPE (I, V)
AOx03TYP :=
AOx03 AQTY LOW (–2147483647 to +2147483647)
AOx03AQL :=
AOx03 AQTY HI (–2147483647 to +2147483647)
AOx03AQH :=
If AOx03TYP = I
AOx03 LO OUT VAL (–20.480 to +20.480 mA)
AOx03L :=
